GENERAL

• Enclosure Type

  Desktop 1U

• Subtype

  Gigabit Ethernet

• Ports

  24 x 10/100/1000 + 4 x shared SFP

• MAC Address Table Size

  10K entries

• Status Indicators

  Port status, port transmission speed, port duplex mode, power, link/activity

• Manufacturer

  Asus

POWER DEVICE

• Nominal Voltage

  AC 120/230 V

• Frequency Required

  50/60 Hz

• Power Consumption Operational

  50 Watt

• Type

  internal power supply

NETWORKING

• Cabling Type

  Ethernet 1000Base-T, Ethernet 100Base-TX, Ethernet 10Base-T

• MAC Address Table Size

  10K entries

• Subcategory

  network hubs and switches

• Subtype

  Gigabit Ethernet

• Form Factor

  desktop

• Type

  switch

• Connectivity Technology

  wired

• Features

  auto-sensing per device, auto-uplink (auto MDI/MDI-X), flow control, layer 2 switching

• Compliant Standards

  IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u

• Ports Qty

  24

• Manageable

  No

• Switching Protocol

  Ethernet

• Communication Mode

  full-duplex, half-duplex

MISCELLANEOUS

• Compliant Standards

  FCC Class A certified, CCC

• Rack Mounting Kit

  included

• Height (Rack Units)

  1 m

INTERFACE PROVIDED

• Qty

  24, 4

• Connector Type

  SFP (mini-GBIC)

CHASSIS

• Built-in Devices

  LED panel

ENVIRONMENTAL PARAMETERS

• Min Operating Temperature

  32 °F

• Max Operating Temperature

  104 °F

• Humidity Range Operating

  5 - 95%

HEADER

• Brand

  ASUS

• Product Line

  ASUS GigaX

• Model

  1124B

• Packaged Quantity

  1

• Compatibility

  PC

DIMENSIONS & WEIGHT

• Width

  17.5 in

• Depth

  7.9 in

• Height

  1.7 in

PORTS

• Type

  10/100/1000

• Qty

  24

PORTS (2ND)

• Type

  shared SFP

• Qty

  4

SLOT REQUIRED

• Type

  none

GENERAL

• Manufacturer

  Asus
