Output

  • Output power capacity
    405Watts / 700VA
  • Max Configurable Power (Watts)
    405Watts / 700VA
  • Nominal Output Voltage
    230V
  • Output Frequency (sync to mains)
    47 - 63 Hz
  • Output Frequency (not synced)
    50Hz +/- 0.1% for 50Hz nominal
  • Other Output Voltages
    220
  • Waveform type
    Stepped approximation to a sinewave
  • Output Connections
    (4) Australian (selector_surgetitle)
    (4) Australian (Battery Backup)
  • Output Voltage Tolerance
    +/- 5% static and 100% load step
  • Transfer Time
    6ms typical : 10ms maximum

Input

  • Nominal Input Voltage
    230V
  • Input frequency
    50/60 Hz +/- 5 Hz (auto sensing)
  • Input Connections
    Australian/Chinese
  • Cord Length
    1.83meters
  • Maximum Input Current
    10.0A

Batteries & Runtime

  • Battery type
    Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
  • Typical recharge time
    16hour(s)
  • Replacement Battery
    RBC17
  • Expected Battery Life (years)
    3 - 5
  • Battery Volt-Amp-Hour Capacity
    86

Communications & Management

  • Interface Port(s)
    USB
  • Control panel
    LED status display with On Line : On Battery : Replace Battery and Overload indicators

Surge Protection and Filtering

  • Surge energy rating
    310Joules
  • Data Line Protection
    Analog phone line for phone/fax/modem/DSL (RJ-45 connector), Network line - 10/100 Base-T Ethernet (RJ-45 connector)
  • Filtering
    Full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449
ModelBack-UPS ES
TypeLine-Interactive
Packing Weight8000 g
Additional FeaturesAdjustable voltage sensitivity Audible alarms Automatic self-test Battery failure notification Battery replacement without tools User-replaceable batteries Battery-protected and surge-only outlets Cold-start capable Dataline surge protection Hot-swappable batteries Safety-agency approved USB connectivity
VA Rating Group501-1000 VA
Watts Group0-500 Watts
VA Rating700 VA
Watts405 W
AC Outlets Quantity8
Packing Width130 mm
Packing Depth410 mm
InterfaceUSB 2.0
Packing Height280 mm
Output Voltage230 V
Battery Recharge Time16 hrs
Package TypeBOX
