Eaton 5P650i Uninterruptible Power Supply Rack 1U UPS 650VA 420W
Product Code: 5P650iR
Price:
$675.00
Sold Out
Share This Item:
EATON LINE INTERACTIVE 5P UPS 650VA / 420W - RACK 1U
| Basic | |
|---|---|
| Backup/Run Time (Full Load): | 2 Minute |
| Backup/Run Time (Half Load): | 9 Minute |
| Brand Name: | Eaton |
| Form Factor: | Rack-mountable |
| Input Voltage: | 220 V AC |
| Load Capacity (VA): | 650 VA |
| Load Capacity (Watt): | 420 W |
| Plug/Connector Type: | IEC 60320 C14 |
| Product Type: | Line-interactive UPS |
| Rack Height: | 1U |
| Receptacles: | 4 x IEC 60320 C13 |
| Battery Information | |
|---|---|
| Backup/Run Time (Full Load): | 2 Minute |
| Backup/Run Time (Half Load): | 9 Minute |
| General Information | |
|---|---|
| Brand Name: | Eaton |
| Manufacturer Part Number: | 5P650IR |
| Manufacturer: | Eaton Corporation |
| Product Model: | 5P |
| Product Name: | 5P 650i VA Rack 1U |
| Product Type: | Line-interactive UPS |
| Interfaces/Ports | |
|---|---|
| Serial Port: | Yes |
| Total Number of Expansion Slots: | 1 |
| USB: | Yes |
| Miscellaneous | |
|---|---|
| Certifications & Standards: |
|
| Physical Characteristics | |
|---|---|
| Depth: | 364 mm |
| Form Factor: | Rack-mountable |
| Height: | 43.2 mm |
| Rack Height: | 1U |
| Weight (Approximate): | 3.90 kg |
| Width: | 438 mm |
| Power Description | |
|---|---|
| Input Voltage: | 220 V AC |
| Load Capacity: | 650 VA/420 W |
| Output Voltage: | 208 V AC |
| 220 V AC | |
| 230 V AC | |
| 240 V AC | |
| Technical Information | |
|---|---|
| Plug/Connector Type: | IEC 60320 C14 |
| Receptacles: | 4 x IEC 60320 C13 |
| Model | 5P650iR |
| Specification | http://powerquality.eaton.com/5P650iR.aspx?CX=22 |
| Type | Rack |
| Additional Features | Line interactive : Regulates power fluctuations (AVR with buck and boost), and delivers pure sinewave output Intuitive graphical LCD for localised diagnostics at a glance Individually controlled outlets to maximize backup time, provide remote reboot and sequential start-up Hot swappable batteries allowing easy replacement of the batteries without powering down connected loads High density power protection in tower and rack 1U format up to 1.5kVA Best-in-class power management capabilities (USB & Serial ports, Slot for optional SNMP/Web card) |
| Packing Weight | 9200 g |
| VA Rating Group | 501-1000 VA |
| Watts Group | 0-500 Watts |
| VA Rating | 650 VA |
| Watts | 420 W |
| AC Outlets Quantity | 4 |
| Packing Width | 234 mm |
| Packing Depth | 442 mm |
| Interface | RS-232 USB 2.0 |
| Packing Height | 326 mm |
| Output Voltage | 230 V |
| Input Voltage Range | 160-294V |
| Output Receptacles | 4 x IEC-320-C13 |
| Connection | 1 x IEC-320-C14 |
