Ergotron 45-479-026 Dual Monitor Wall Arm Mount Screen Display LED LCD TV Holder Bracket Up to 32"

Two-Monitor Mount
Choose a monitor arm that’s as adaptable as you. With the Wall Dual Monitor Arm, you can easily reposition two 32" monitors using patented Constant Force Technology. The hinged bow lets you easily pan your monitors for screen sharing and the most comfortable views.



Personalized views

• Independent pivots rotate, pan, and tilt each monitor

Rotation stop

• Avoid hitting cube walls with a rotation-stop on the base

Saves space

• Places screen in the best view and open up the valuable work area

Sleek build

• Cables stay hidden under the arm and through the extension



• Includes arm, extension, hinge bow, 2 monitor pivots, handle, wall mount, and monitor mounting hardware
• Arm folds back over the base into a compact retracted position; perfect for tucking under systems furniture storage shelves or cabinets in space-constrained areas
• Portrait/landscape rotation with lockout
• Streamline cable management that routes cables under arm and within the extension
• Mounting Standards: VESA FDMI MIS–D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm). The optional VESA Bracket Adaptor Kit (97-759) allows the attachment of displays with VESA hole patterns of 200 x 100, 200 x 200, 400 x 200 mm, 400 x 300 mm or 400 x 400 mm
• Mounting Options: Attaches directly to sturdy vertical surfaces. Where applicable, apply to wood stud. Also attaches to wall track using bracket 97-091 (order separately)
• Weight Capacity: Individual LCD weight = 5–17.5 lbs (2.3–7.9 kg) per monitor. Total LCD weight = 10–35 lbs (4.6–15.8 kg)
• Monitor depth greater than 2.5" (6.4 cm) may diminish the capacity
• The hinged bow turns 40° inward and 90° outward
• The monitor can be rotated 360° at the connection point of arm and extension; rotation is restricted to 180° at the connection point of extension and base
• Tilt Range: 70° backward, 5° forward
• Pivots feature quickly to install and release and feature effortless portrait to landscape 6° pan and tilt
• Up to 24.5" (60 cm) extended reach and 11.5" (29.2 cm) vertical height adjustment



Specification:

• Screen ≤32"
• Capacity 4.5–15.9 kg
• Lift 29.2 cm
• Tilt 75°
• Pan 180°
• Rotation 360°
• Vesa MIS-D
