| HARDWARE FEATURES |
| Standards and Protocols | IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| Interface | 16 10/100Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
100BASE-TX: UTP category 5, 5e or above cable (maximum 100m) |
| Fan Quantity | Fanless |
| Power Supply | 100-240VAC, 50/60Hz |
| Power Consumption | Maximum: 2.23W (220V/50Hz) |
| Dimensions ( W x D x H ) | 17.3*7.1*1.7 in. (440*180*44 mm) |
| PERFORMANCE |
| Switching Capacity | 3.2Gbps |
| Packet Forwarding Rate | 2.38Mpps |
| MAC Address Table | 8K |
| Buffer Memory | 2Mb |
| Green Technology | Innovative energy-efficient technology saves power up to 70% |
| Transfer Method | Store-and-Forward |
| OTHERS |
| Certification | FCC, CE, RoHS |
| Package Contents | 16-Port 10/100Mbps Rackmount Switch
Power Cord
Installation Guide
Rackmount Kit
Rubber Feet |
| System Requirements | Microsoft® Windows® 8, 7,Vista™, XP or MAC® OS, NetWare®, UNIX® or Linux. |
| Environment | Operating Temperature: 0?~40? (32?~104?);
Storage Temperature: -40?~70? (-40?~158?);
Operating Humidity: 10%~90% non-condensing;
Storage Humidity: 5%~90% non-condensing |
| Power Consumption | 2.23 W |
| Quantity Ports | 16 |
| Additional Features | Supports MAC address self-learning and auto MDI/MDIX Standard 19-inch rack-mountable steel case Innovative energy-efficient technology saves power up to 40% 100% Data filtering rate eliminates all error packets |
| Standards Compliance | IEEE 802.3u IEEE 802.3x IEEE 802.3i |
| Features | Green Technology, saving power up to 80% |
| Switching Capacity | 3.2 GB/s |
| Model | TL-SF1016 |
| Packing Weight | 700 g |
| Packing Width | 480 mm |
| Packing Depth | 210 mm |
| Packing Height | 70 mm |
| Package Type | BOX |
